BUMBLEBEE

The Bumblebee headlight module delivers an even, streak-free light pattern that greatly improves the driver’s vision. This ECE-approved headlight module comes in high beam and low beam versions, specifically designed and optimized for heavy-duty vehicles. Thanks to the well-balanced color temperature, the driver will stay alert longer. The Bumblebee’s exceptional light output in combination with the long light range places it among the top of the currently available options on the market.

Not all products are available in all markets. During continuous improvement specifications and design are changing. All values are nominal values. Illustrations do not necessarily show the design of every version and some features are version specific. The lumens output varies depending on lens colour.

Key Features

  • ECE-approved module
  • Easily adapted to your custom design
  • Light pattern optimized for heavy-duty vehicles

Connectors


Built-in Deutsch DT-2 (2-pin)

Technical Data

Colour Temperature5800K
Nominal Voltage DC12V, 24V
Input Voltage DC9 - 32V
Power ConsumptionHigh Beam 18W, Low Beam 18W
Nominal Current atHigh/Low Beam 1.5 A@12V, 0.75 A@24V
ConnectorBuilt-in Deutsch DT-2 (2-pin)
Mount3 pcs M6 screw
Shock60G
Vibration6Grms 24-1000Hz
LensGlass
Body / HousingAluminium
Weight0.95kg
IP RatingIP68, IP6K9K
Salt Spray TestISO 9227 240H
EMCCISPR 25 Class 5, ISO 13766, ISO 14982, ISO 7637-2, ISO 10605, ISO 11452, EN 61000-4-2, EN 13309
ECE ApprovalsHigh Beam: ECE R149, Low Beam RHT: ECE R149, Low Beam LHT: ECE R149, Low Beam Symmetric: ECE R149
Operating Temperatures-40°C... +85°C (Full Power -40°C... +50°C)
ElectronicsIsolated

Light Patterns

Click to zoom

Drawings

Click to zoom

Part Numbers

High Beam: 960-432B (ECE R149)
Low Beam Symmetric: 960-434B (ECE R149)
Low Beam LHT: 960-435B (ECE R149)
Low Beam RHT: 960-433B (ECE R149)
