CG410 - Canis GO - NORDIC LIGHTS® - Herrmans Oy Ab

CANIS GO 410

Our entry-level Canis GO 410 is as good as it gets.
While it is lighter in weight than the original Canis work light, the operational lumens output is just as high. Best suited to construction, forestry, agriculture, and material handling, the Canis GO 410 has a round form factor and pedestal mounting, it produces zero emissions (EMC CISPR 25 class 5) and its light output is 1000 lumens.

Not all products are available in all markets. During continuous improvement specifications and design are changing. All values are nominal values. Illustrations do not necessarily show the design of every version and some features are version specific. The lumens output varies depending on lens colour.

Key Features

  • Dimmable & Cost-effective all-rounder
  • Operational lumens output: 1000lm
  • Pure performance in a compact design

Connectors


Built-in Deutsch DT-2 (2-pin)

Technical Data

Theoretical Lumens Output1600lm
Operational Lumens Output1000lm
Colour Temperature5000K
Nominal Voltage DC12 - 24V
Input Voltage DC9 - 16V, 18 - 32V
Power Consumption16W
Nominal Current at24V=0.6A, 12V=1.05A
ConnectorBuilt-in Deutsch DT-2 (2-pin)
MountSingle Bolt M8
Shock60G
Vibration8Grms 24-2000Hz
LensGrilamid® (registered trademark of EMS-GRIVORY)
Body / HousingAluminium
Weight0.6kg
IP RatingIP68, IP6K9K
Salt Spray TestISO 9227 240H
EMCCISPR 25 Class 5, EN12895, ISO 13766, ISO 14982, ISO 7637-2
Operating Temperatures-40°C... +85°C (Overheat protected)

Light Patterns

Click to zoom

Drawings

Click to zoom

Part Numbers

Wide Flood: 988-101B
Flood: 988-102B
