SCORPIUS 400 BLUE

NORDIC LIGHTS® Scorpius 400 Blue is a state-of-the-art blue crop sprayer light and the latest addition to our successful Scorpius work light family. Originally developed for the mining industry, the standards for this work light are set high. Adapted to the agricultural industry, and designed specifically for crop sprayers, the Scorpius 400 Blue LED pencil beam illuminates the boom, the nozzles and the spray pattern. It has an excellent luminous intensity of 30 000 candela, making it the best blue pencil beam you will find on the market.

Read more
Not all products are available in all markets. During continuous improvement specifications and design are changing. All values are nominal values. Illustrations do not necessarily show the design of every version and some features are version specific. The lumens output varies depending on lens colour.

Key Features

  • Optimized illumination of boom and spray pattern
  • Light color blue, 475 nm
  • Superior electromagnetic compatibility (CISPR 25 Class 5)

Connectors


Built-in Deutsch DT-2 (2-pin)

Technical Data

Light ColorBlue, 475nm
Luminous intensity30000cd
Nominal Voltage DC12V, 24V
Input Voltage DC9 - 16V, 18 - 32V
Power Consumption42W
Nominal Current at24V=2.1A, 12V=4.2A
ConnectorBuilt-in Deutsch DT-2 (2-pin)
MountSingle Bolt M10
Shock60G
Vibration15.3Grms 24-2000Hz
LensGrilamid® (registered trademark of EMS-GRIVORY)
Body / HousingAluminium
Weight1.1kg
IP RatingIP68, IP6K9K, IP6K96, IPX8
EMCCISPR 25 Class 5, ISO 13766, ISO 14982, ISO 7637-2, EN 61000-4-2
Operating Temperatures-40°C... +85°C (Overheat protected)

Light Patterns

Click to zoom

Drawings

Click to zoom

Part Numbers

Pencil Beam: TBA
