SCORPIUS GO 420

Our entry-level Scorpius GO 420 is easy to use.
It is lighter in weight than the original Scorpius work light, and the light pattern options are three: flood, wide flood and high beam. Useful in construction, forestry, agriculture, and material handling, the Scorpius GO product family has a square form factor and pedestal mounting. The Scorpius GO 420 produces zero emissions (EMC CISPR 25 class 5) and its light output is 2000 lumens.

Not all products are available in all markets. During continuous improvement specifications and design are changing. All values are nominal values. Illustrations do not necessarily show the design of every version and some features are version specific. The lumens output varies depending on lens colour.

Key Features

  • Dimmable & Cost-effective all-rounder
  • Operational lumens output: 2000lm
  • Pure performance in a compact design

Connectors


Built-in Deutsch DT-2 (2-pin)

Technical Data

Theoretical Lumens Output3000lm
Operational Lumens Output2000lm
Colour Temperature5000K
Nominal Voltage DC12 - 24V
Input Voltage DC9 - 16V, 18 - 32V
Power Consumption29W
Nominal Current at24V=1.05A, 12V=1.85A
ConnectorBuilt-in Deutsch DT-2 (2-pin)
MountSingle Bolt M8 / M10
Shock60G
Vibration8Grms 24-2000Hz
LensGrilamid® (registered trademark of EMS-GRIVORY)
Body / HousingAluminum
Weight0.6kg
IP RatingIP68, IP6K9K
Salt Spray TestISO 9227 240H
EMCCISPR 25 Class 5, EN12895, ISO 13766, ISO 14982, ISO 7637-2
Operating Temperatures-40°C... +85°C (Overheat protected)
ElectronicsIsolated

Light Patterns

Click to zoom

Drawings

Click to zoom

Part Numbers

High Beam: 988-297B
Flood: 988-203B
Wide Flood: 988-204B
